Sprayers with transverse axial blowers
diameters 24”, 28” and 32”

Better positioning — targeted air supply guarantees low wear and less wastage of the spray liquid, therefore environmentally friendly and efficient.

Capacity:

• 1000 liters
• 1500 liters
• 2000 liters

Features

Air blower design

• Galvanized housing
• Low power consumption and low noise thanks to the special aerodynamic wing
• Optimal performance through direct air intake
• Nozzles are outside the airflow
• 2 — step gear with zero position
• Individual anti-drip nozzles swiveling and removable
• Optional nozzles

Optional equipment

• Electric remote control SC10/E2 to E4 with 2 or 4 boom sections, solenoid valves and mechanical pressure regulator
• Electric remote control SC100/E2 to E6 with 2,4 or 6 boom sections, solenoid valves and electric pressure regulator, tractor cab pressure indication
• Electric remote control SC100/E2 to E6 with LCD display and touch screen, digital pressure and liquid level indicator, 2 to 8 boom sections possible
• Spray computer SPRAYDOS or SC100RC, 2 — 8 boom sections possible (SC100RC equipment is the same as SC100CE, but only as a control unit)
• Different tire options
• Twin or triple anti-drip nozzles
• Injection nozzles
• Single-sided fan cover

Technical data

Standard equipment

• Rugged galvanized frame construction
• Adjustable axle
• Supplied with cardan shaft
• Fiberglass tank with optimally positioned air intakes and built-in water tank for rinsing the tank, “spraying” / “rinsing” switchable even if the tank is full or partially filled, level indicator, agitator, two filling holes with filter, handwash tank with drain cock
• Filters: strainer, suction filter with automatic shut-off, pressure filter with quick cleaning, tool-free maintenance
• Piston diaphragm pump: Type „IDS1401″(140l./50bar)
• Controls: mechanical remote control type „MSC CD13″, central shut-off, boom section switch (two sections), pressure adjustment from the tractor cab, with pressure gauge
